The DD series is a series of multi-channel professional Class D amplifiers, designed with the target of outstanding reliability. In particular, the innovative design of the automatic temperature control system and the unique limiting function both contribute to the high efficiency of product performance. With the standardized design and a complete product line, the DD series help meet the needs of diversification in the professional sound reinforcement industry. A comprehensive interface and simplified control functions are in place to contribute to your convenient and flexible applications.
Power Stereo 8Ω: | 2 x 2000W |
Power Stereo 4Ω: | 2 x 3400W |
Power Stereo 2Ω: | 2 x 4760W |
Power Bridge 16Ω: | 1 x 4000W |
Power Bridge 8Ω: | 1 x 6800W |
Power Bridge 4Ω: | 1 x 9520W |
Output RMS voltage: | 126.5V |
Gain (Rated Power, 1kHz): | Selectable 41dB/38dB/35dB/32dB |
Default Gain (rated Power, 1kHz): | Typical:0.0% (10% Rated Power, 8Ω) |
Cross-talk: | ≥90dB (20Hz-1kHz, below Rated Power) |
Frequency response: | Typical: +0, -0.5dB (10% Rated Power, 20Hz-20kHz, 8Ω) |
Input impedance: | 20kΩ (Balance), 10kΩ (Unbalance) |
Damping factor: | Typical: 5000(Ω, 20Hz-200Hz) |
SNR: | ≥105dB (A weighted, 20Hz-20kHz, 8Ω) |
Main Power: | 90~260VAC, 50/60Hz |
Protection: | Under voltage, DC, Over temperature; Limiter: Over temperature, Over load, Short. |
Dimension (W x H x D): | 483x45x370mm |
Net Weight: | 9kg |
